12.95寸高清显示屏1200X1920,Incell
-
品牌：TOPVIEW（拓浦）
型号：C129MFX-M01
规格：1920×1200 12.8英寸
- 咨询热线：李先生(Jacky)：139 2362 5299 明先生(Mike)：139 2387 9327 李先生(Leo)： 139 1709 9753
-
产品详情
| Item | Specification |
| Brand | TOPVIEW |
| Display Size | 12.95 inch |
| Model | C129MFX-M01 |
| Aspect Ratio | 16:10(H:V) |
| Resolution | 1200(H) x1920 (V) |
| Active Area | 174.312(H) x 278.899(V)mm |
| Pixel Pitch | 0.04842(H) x 0.14526(V)mm |
| Outline Dimension | 190.36(H) x291.26(V) x 5.07(D)mm |
| Support color | 16.7M |
| Color Gamut | 92% NTSC |
| Display mode | Normally black(IPS) |
| View angle | L/R/U/D 85/85/85/85 |
| Brightness | 500-800 cd/㎡ |
| Contrast Ratio | 1500：1 |
| Interface | MIPI, 30 pins Connector |
| Backlight | 30000 hours, with LED driver |
| Operating temp. | -20℃ ~ +70℃ |
| Storage temp. | -30℃ ~ +80℃ |
-
